Our Laboratory Equipment

Petrol

GDI calibration system

  • Leakage test
  • Injector calibration
  • Flow test (dynamic and static)

Diesel

Functional test of nozzles

  • Opening pressure measurement
  • Spray pattern measurement

High-pressure test bench

  • Up to 3000 bar

Hydroerosive grinding

  • Hydroerosive module grinding machine
    flow range 75…15.000 ml/min
  • Hydroerosive High flow grinding machine
    flow range up to 35,000 ml/min
  • Flow test   75…3,000 ml/min
  • High flow test   2,500…40,000 ml/min

Assembly and testing

  • μHammering demonstrator
  • Air tightness test
  • Shock absorber tester

In addition, there is calibration and measurement equipment available for the following physical variables

  • Pressure (0..2500 bar abs.)
  • Force (0..100 kN)
  • Active temperature control (-40..650 °C)
  • Viscosity (10…1000mPas)
  • Density pressure dependent 1.4..1000kg/m³ at 0…500bar)
  • Measurement microscopy with a 2,500 x magnification
